A Beginner’s Guide to InfluxDB: A Time-Series Database

A time series database (TSDB) is specifically made for data that can be evaluated as a "time-series," which includes sensor outputs, market trends, CPU utilization, and application performance metrics. Most popular types of databases (both SQL and NoSQL) are not optimized for handling large-scale scans, or summarization or aggregation of time-series data.Time-series databases have built-in functionality to work with aggregation, down-sampling, data lifecycle management and summarization. Let’s look at one of the popular time-series databases, InfluxDB. InfluxDB uses the line protocol for sending and storing data.

Line Protocol

The line protocol is the text-based format that uses the syntax below to write points to InfluxDB.

<measurement>[,<tag_key>=<tag_value>[,<tag_key>=<tag_value>]] <field_key>=<field_value>[,<field_key>=<field_value>] [<timestamp>]

The above syntax is used to insert a single point to an InfluxDB database. Since InfluxDB is a time-series database, the point here is analogous to a point on a graph that is representing a time-series data. The collection of points is called a series. Next, let’s look at all the four components of the point.

The first component, Measurement for an InfluxDB, is similar to a Table for a SQL database. Measurement holds all the tags, fields and time values. It makes sense to name the measurement such that it describes the data contained in it.

The two components tag set and field set in the line protocol are sets, meaning a key-value pair. Tag Key and Tag Value are both stored in InfluxDB as strings. In contrast, only Field Key can be a string but the Field Value can contain strings, integers, floats and Booleans too. The field value is the actual data that we want to save to a database and it is always accompanied by a timestamp, which makes sense since we are inserting a record to a time-series database.

As you have guessed by now, the field value, which is the actual data or the field set in general, as well as a timestamp, are essential components without which we can not save a point to the database. Although tag set is an optional component, it is a good practice to use, since it is indexed and would be useful in faster querying of data, as opposed to the field set, which is not indexed.

The last, and most critical component of the line protocol is time, which is a timestamp in the RFC3339 UTC format. The timestamp precision can be in seconds, milliseconds, microseconds or nanoseconds.

Writing Data to InfluxDB

Data can be written to InfluxDB using a command line interface(CLI) using InfluxDB API or client libraries. A basic CLI tool like curl can be used to create and write to a database. InfluxDB provides client libraries for most popular languages like Java, PHP, Python, C++ and Go. I chose to use the Python influxdb-client. Below is an example of how to write the data using it.

  • Start with importing the required modules in your program

    from influxdb_client import InfluxDBClient, Point, WritePrecision
    from influxdb_client.client.write_api import SYNCHRONOUS

  • Then create an InfluxDB client (mention your URL, token and org as below) and a writer object

    url = "<my-url>"
    token = "<my-token>"
    client = InfluxDBClient(url=url, token=token, org=org)
    write_api = client.write_api(write_options=SYNCHRONOUS)

  • Use the module ‘Point’ that you have imported from influxes_client to convert your data to point, or alternatively create a point yourself

    # Using built-in functionality to create Point
    p = Point("my_measurement").tag("location", "location1").field("temperature", 25).time(datetime.utcnow(),WritePrecision.NS)

    # Creating the point manually
    measurement = "my_measurement"
    tag_set = "location=location1"
    field_set = "temperature=25"
    date_in_nano = str(int(datetime.datetime.utcnow().timestamp() * 1000000000))
    p = f"{measurement},{tag_set} {field_set} {date_in_nano}"

  • Finally, write the point to a database.

    org = "<my-org>"
    bucket = "<my-bucket>"
    write_api.write(bucket, org, p)


Here, the bucket is a location where the data is stored. It has a retention policy and org attached to it. Retention policy consists of duration, replication factor, and shard group duration. The default duration values for these are infinite, one day, and seven days, respectively.

Querying Data from InfluxDB

Data stored in the InfluxDB can be queried using either a table structure or stream.

  • Once again, start by importing the required modules and creating an influxdb client as well as query object

    from influxdb_client import InfluxDBClient

    url = "<my-url>"
    token = "<my-token>"
    client = InfluxDBClient(url=url, token=token, org=org)
    query_api = client.query_api()

  • You can query InfluxDB using a table structure. See the sample code below to see how.

    # query using table structure
    tables = query_api.query('from(bucket:"my-bucket") |> range(start: -10m)')
    for table in tables:
        print(table)
        for record in table.records:
            print(record.values)

  • Use the sample code below for querying using stream

    # Query using stream
    records = query_api.query_stream('from(bucket:"my-bucket") |> range(start: -10m)')
    for record in records:
        print(f'Temperature at {record["location"]} - {record["_value"]}')


For more information on Influx query language, please refer to its documentation.

Grafana with InfluxDB

Since InfluxDB is a time-series database, wouldn’t it be cool to actually be able to see the data like an actual graph? Grafana can be used with InfluxDB for this exact purpose! You can follow the integration of Grafana with the InfluxDB here. Pretty dashboards can be created using Grafana that actually show how your data changes over time.

There is a lot more you can do with time-series data, such as checking metrics, tracking errors, keeping up with market trends, and much, much more! Grafana integration provides visual data for analysis. In addition, there are more ways you can use and query InfluxDB to make it work for your use case. I hope this post has provided an easy start to using InfluxDB.

Post by Ketki V Deshpande
Jun 29, 2021 11:34:00 AM
